Hikvision DS-7616NXI-K2/16P D PL – IP camera
Technical specifications
| Supported resolutions | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|---|---|
| Certification | EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
| Networking standards | IEEE 802.3af |
| Networking standards | IEEE 802.3at |
| DC-in jack | Yes |
| Maximum resolution | 1920 x 1080 pixels |
| Ethernet LAN data rates | 10 |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 100 |
| Weight | 3 kg |
| Product colour | Black |
| Output bandwidth | 160 Mbit/s |
| Video codecs | H.265+/H.265/H.264+/H.264 |
| HDMI output | Yes |
| Input bandwidth | 160 Mbit/s |
| USB 2.0 ports quantity | 1 |
| Audio RCA inputs | 2 |
| Video input channels | 16 channels |
| Power over Ethernet (PoE) ports quantity | 16 |
| HDD interface | SATA |
| Operating relative humidity (H-H) | 10 – 90% |
| VGA (D-Sub) output ports | 1 |
| Operating temperature (T-T) | -10 – 55 °C |
| Height | 52 mm |
| Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Depth | 315 mm |
| Power consumption (typical) | 15 W |
| HDD capacity | 0 GB |
| Power over Ethernet (PoE) | Yes |
| Number of HDDs supported | 2 |
| Width | 385 mm |
| HDMI ports quantity | 1 |
| Maximum storage capacity | 32 TB |
| Warnings | The product must be disposed of in accordance with local hazardous waste regulations. |
| Warnings | Do not expose the device to moisture or extreme temperatures. |
| Warnings | The appliance should be installed by a qualified professional. |
