Description
Intel Core i7-12700F processor 25 MB Smart Cache Box
Technical specifications
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
|---|---|
| Intel® Turbo Boost Technology | 2.0 |
| Discrete graphics card model | Not available |
| Enhanced Intel SpeedStep Technology | Yes |
| On-board graphics card model | Not available |
| PCI Express configurations | 1×16+1×4 |
| PCI Express configurations | 2×8+1×4 |
| PCI Express slots version | 5.0 |
| PCI Express slots version | 4.0 |
| Processor package size | 45 x 37.5 mm |
| Thermal Monitoring Technologies | Yes |
| Processor codename | Alder Lake |
| Maximum internal memory | 128 GB |
| Embedded options available | No |
| CPU configuration (max) | 1 |
| Processor family | Intel® Core™ i7 |
| Non-ECC | Yes |
| Warnings | Avoid shocks and drops so as not to damage delicate components. |
| Warnings | Ensure that the processor is adequately cooled to prevent overheating. |
| Warnings | Do not touch the processor pins to avoid electrostatic damage. |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Target market | Gaming, Content Creation |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Cooler included | Yes |
| Intel® Boot Guard | Yes |
| Intel® Speed Shift Technology | Yes |
| Efficient cores | 4 |
| Intel® Thread Director | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 4.9 GHz |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
| Intel® Standard Manageability (ISM) | Yes |
| Execute Disable Bit | Yes |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Performance-core base frequency | 2.1 GHz |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory types supported by processor | DDR5-SDRAM |
| Intel® Secure Key | Yes |
| Performance cores | 8 |
| Processor socket | LGA 1700 |
| Use conditions | PC/Client/Tablet |
| Supported instruction sets | SSE4.1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Status | Launched |
| Performance-core boost frequency | 4.8 GHz |
| Maximum number of DMI lanes | 8 |
| Supported instruction sets | AVX 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Supported instruction sets | SSE4.2 |
| Scalability | 1S |
| Processor cache type | Smart Cache |
| Intel® Optane™ Memory Ready | Yes |
| Processor base power | 65 W |
| Processor cache | 25 MB |
| Processor operating modes | 64-bit |
| Discrete graphics card | No |
| Maximum turbo power | 180 W |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Processor generation | 12th gen Intel® Core™ i7 |
| Harmonized System (HS) code | 85423119 |
| Processor model | i7-12700F |
| Intel® OS Guard | Yes |
| Box | Yes |
| Tjunction | 100 °C |
| Processor cores | 12 |
| Maximum number of PCI Express lanes | 20 |
| Bus type | DMI4 |
| Memory channels | Dual-channel |
| Processor threads | 20 |
| On-board graphics card | No |
| Memory bandwidth (max) | 76.8 GB/s |
| Launch date | Q1'22 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Idle States | Yes |
| Processor manufacturer | Intel |
| Intel 64 | Yes |
| Market segment | Desktop |
| Processor ARK ID | 134592 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
